HF SSB Transceiver TS-120S

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543709) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543710) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543711) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543713) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543714) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543715) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543716) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543717) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543718) Amat TRX

HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 2543719) Amat TRX
HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 354021) Amat TRX HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 412351) Amat TRX
HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 399354) Amat TRX HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 411123) Amat TRX
HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 412350) Amat TRX HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 412353) Amat TRX
Use red slider bar for more.
HF SSB Transceiver TS-120S; Trio-Kenwood (ID = 354021) Amat TRX
Trio-Kenwood: HF SSB Transceiver TS-120S [Amat TRX] ID = 354021 480x245
Select picture or schematic to display from thumbnails on the right and click for download.
For model HF SSB Transceiver TS-120S, Trio-Kenwood Electronic Inc.; Komagane:
ebay 270152875108

Country:  Japan
Manufacturer / Brand:  Trio-Kenwood Electronic Inc.; Komagane
alternative name

Trio Corp.
Brand
Jennen
Year: 1979 ? Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) 106:
Main principle Transceiver
Wave bands Short Wave (SW only)
Details
Power type and voltage Powered by external power supply or a main unit. / DC 13.8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: HF SSB Transceiver TS-120S - Trio-Kenwood Electronic Inc.;
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 241 x 94 x 235 mm / 9.5 x 3.7 x 9.3 inch
Notes

Kenwood HF SSB/CW Transceiver TS-120S.

Final Power input:

  • SSB: 200 W PEP, 160 W PEP in 10 m Band
  • CW: 160 W, 140 W in 10 m band

Frequency ranges:

  • 3.5-4.0 MHz
  • 7.0-7.5 MHz
  • 14.0-14.5 MHz
  • 21.0-21.5 MHz
  • 28.0-29.7 MHz
  • RX only 15.0-15.5 MHz for WWV

VOX, NB, RIT, digital readout.

Net weight (2.2 lb = 1 kg) 5.6 kg / 12 lb 5.4 oz (12.335 lb)
Mentioned in Richter-Katalog 1980
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
