• Country
• Japan

• Manufacturer / Brand
• Kenwood, Trio-Kenwood Inc.; Komagane

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 208314

• • alternative name: Trio Corp.
  • Brand: Jennen

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-120; 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 50 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Two-Four Receiver KR-5340 - Kenwood, Trio-Kenwood Inc.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 500 x 153 x 360 mm / 19.7 x 6 x 14.2 inch

• Notes
• Am /FM 2-Kanal/4-Kanal-Receiver.
  Sinusleistung 4-Kanalbetrieb 4x 10 Watt, 2-Kanalbetrieb 2x 25 Watt an 8 Ohm.
  Klirrfaktor bei Nennleistung 0,8%.
  20 - 40000Hz, Lautsprecherimpedanz 4-16 Ohm. Loudness

• Net weight (2.2 lb = 1 kg)
• 14.5 kg / 31 lb 15 oz (31.938 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
