VFO-5D

VFO-5D; Trio-Kenwood (ID = 1918759) Amateur-D VFO-5D; Trio-Kenwood (ID = 2113623) Amateur-D
VFO-5D; Trio-Kenwood (ID = 2113625) Amateur-D VFO-5D; Trio-Kenwood (ID = 2113626) Amateur-D
Use red slider bar for more.
VFO-5D; Trio-Kenwood (ID = 1918759) Amateur-D
Trio-Kenwood: VFO-5D [Amateur-D] ID = 1918759 1200x1272
Select picture or schematic to display from thumbnails on the right and click for download.
For model VFO-5D, Trio-Kenwood Electronic Inc.; Komagane

Country:  Japan
Manufacturer / Brand:  Trio-Kenwood Electronic Inc.; Komagane
alternative name

Trio Corp.
Brand
Jennen
Year: 1969 ? Category: Amateur Equipment (Other, but not Key)
Semiconductors (the count is only for transistors) 6:
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / AC 12,6 & DC 150 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: VFO-5D - Trio-Kenwood Electronic Inc.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 7.875 x 8.656 x 7.563 inch / 200 x 220 x 192 mm
Notes

Externer VFO für Trio TS 510

Frequency range:  3.5 -  4.1 MHz
                              7.0 -  7.6 MHz
                             14.0 - 14.6 MHz
                             21.0 - 21.6 MHz
                             28.0 - 28.6 MHz
                             28.5 - 29.1 MHz
                             29.1 - 29.7 MHz

Oscillation Frequency 4.9 - 5.5 MHz
Power: 12.6 V AC 180 mA, 150 V DC 30 mA

Net weight (2.2 lb = 1 kg) 7.3 lb (7 lb 4.8 oz) / 3.314 kg
Mentioned in - - Manufacturers Literature

Model page created by Ottmar Rollmann. See "Data change" for further contributors.
