Wide Band Oscilloscope CS-1557
Kenwood, Trio-Kenwood Inc.; Komagane
- Country
- Japan
- Manufacturer / Brand
- Kenwood, Trio-Kenwood Inc.; Komagane
- Year
- 1972 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 191212
-
- alternative name: Trio Corp.
- Brand: Jennen
Foto del manual Trio
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Number of Transistors
- 44
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 100; 117; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Wide Band Oscilloscope CS-1557 - Kenwood, Trio-Kenwood Inc.;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 225 x 202 x 423 mm / 8.9 x 8 x 16.7 inch
- Notes
-
Y-Bandwidth DC-10 MHz.
Each semiconductor type listed once.
- Net weight (2.2 lb = 1 kg)
- 6.4 kg / 14 lb 1.6 oz (14.097 lb)
- Source of data
- -- Original-techn. papers.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
