Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514753) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514755) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514754) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514756) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514757) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514758) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514759) Radio part

Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 2514760) Radio part
Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 1660705) Radio part Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 1660707) Radio part
Use red slider bar for more.
Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4; Twin Coupler Company (ID = 1660705) Radio part
Twin Coupler Company: Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4 [Radio part] ID = 1660705 880x829
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4, Twin Coupler Company Inc., Poughkeepsie, N.Y., USA

Country:  United States of America (USA)
Manufacturer / Brand:  Twin Coupler Company Inc., Poughkeepsie, N.Y., USA
Year: 1928 ? Category: Radio part (not a module)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Pilot Wasp Short Wave Plug-In Kit Cat No. 180-4 - Twin Coupler Company Inc.,
Material Various materials
Notes

These coils are used for setting the antenna tuning range in conjunction with a set of detector coils in Pilot Wasp Radio Receivers.

There are 5 coils in the antenna set Catalogue # 180-4;

Cat # 180Red Ring17 – 30 M17.6 – 10 MHz
Cat # 181Orange Ring20 – 42 M15 – 7.1 MHz
Cat # 182Yellow Ring48 – 105 M 6.2 - 2.8 MHz
Cat # 183Green Ring93 – 203 M3.2 - 1.5 MHz
Cat # 184Blue Ring200 – 500 M 1.5 – 0.6 MHz

The Data Sheet No. 6 supplied with this box of coils distributed in Australia by Harrington's, Ltd is uploaded to Schematics.
