• Country
• Germany

• Manufacturer / Brand
• Uher Werke; München

• Year
• 1983

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 118775

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 40

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Dry Batteries / 6 × 1,5 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 8 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: CR160 - Uher Werke; München

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 235 x 59 x 185 mm / 9.3 x 2.3 x 7.3 inch

• Notes
• 7 ICs.
  Dolby B and C NR.

• Net weight (2.2 lb = 1 kg)
• 2.7 kg / 5 lb 15.2 oz (5.947 lb)

• Source of data
• - - Data from my own collection

• Mentioned in
• Funkschau (21/1983, S. 56 / Funkausstellung in Berlin)

• Author
• Model page created by a member from FIN. See "Data change" for further contributors.
