CR 160 AV; Uher Werke; München (ID = 1704615) R-Player
Uher Werke; München: CR 160 AV [R-Player] ID = 1704615 800x454
Select picture or schematic to display from thumbnails on the right and click for download.
For model CR 160 AV, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1984–1986 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present. BC337 BC337-25 BC369 BC548 BC550 BC558 BC560 BD136 CD4093 LM1122 LM1123 TDA1151 TDA2009 TL170
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 120; 220; 240; (6 x 1,5) Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: CR 160 AV - Uher Werke; München
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 235 x 200 x 60 mm / 9.3 x 7.9 x 2.4 inch
Notes Stereo Aufnahme und Wiedergabe.
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Source of data - - Data from my own collection / Radiokatalog Band 2, Ernst Erb

Model page created by Peter Böhm. See "Data change" for further contributors.



All listed radios etc. from Uher Werke; München
Here you find 334 models, 306 with images and 165 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
