EG750

EG750; Uher Werke; München (ID = 1769729) Radio

EG750; Uher Werke; München (ID = 1769730) Radio

EG750; Uher Werke; München (ID = 1769731) Radio

EG750; Uher Werke; München (ID = 1769732) Radio

EG750; Uher Werke; München (ID = 1769734) Radio

EG750; Uher Werke; München (ID = 1769735) Radio

EG750; Uher Werke; München (ID = 1769736) Radio

EG750; Uher Werke; München (ID = 1769740) Radio
EG750; Uher Werke; München (ID = 1735894) Radio EG750; Uher Werke; München (ID = 383413) Radio
EG750; Uher Werke; München (ID = 383414) Radio EG750; Uher Werke; München (ID = 383420) Radio
Use red slider bar for more.
EG750; Uher Werke; München (ID = 1735894) Radio
Uher Werke; München: EG750 [Radio] ID = 1735894 1400x631
Select picture or schematic to display from thumbnails on the right and click for download.
For model EG750, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 17: 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC461 2SC535 2SD478 3SK45
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: EG750 - Uher Werke; München
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 135 x 297 mm / 17.1 x 5.3 x 11.7 inch
Notes AM/FM-HiFi-Tuner mit Pegeltongenerator zum Einpegeln von Aufzeichnungsgeräten. Mono-Stereo-Umschalter, AFC, Flutlicht-Linearskala, 2 Drehspulmesswerke.
Net weight (2.2 lb = 1 kg) 6.6 kg / 14 lb 8.6 oz (14.537 lb)
Source of data - - Data from my own collection
Mentioned in -- Original prospect or advert

Model page created by Peter Böhm. See "Data change" for further contributors.
