Royal de Luxe 1970 / 40 Transistoren

Uher Werke; München

  • Year
  • 1970–1972
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 28296

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 40
  • Semiconductors
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110-250 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 10 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Royal de Luxe [1970 / 40 Transistoren] - Uher Werke; München
  • Dimensions (WHD)
  • 465 x 183 x 350 mm / 18.3 x 7.2 x 13.8 inch
  • Notes
  • Tonbandgerät 4-Spur stereo Bandgeschwindigkeit 2.4 / 4.75 / 9.5 / 19cm/sek. Spulendurchmesser bis max. 18cm 40 Trans., 7 Dioden, Synchronplay, 4 Tonköpfe, Hinterbandkontrolle, Aussteuerung über Doppel-Spitzenwert-Zeigerinstrument. Multiplay, Echo, Diapilot zur Steuerung von Diaprojektoren.Tonkopfträger auswechselbar.
  • Net weight (2.2 lb = 1 kg)
  • 13.7 kg / 30 lb 2.8 oz (30.176 lb)
  • Price in first year of sale
  • 1,185.00 DM
  • External source of data
  • Erb
