VG850; Uher Werke; München (ID = 1735898) Ampl/Mixer
Uher Werke; München: VG850 [Ampl/Mixer] ID = 1735898 1400x632
Select picture or schematic to display from thumbnails on the right and click for download.
For model VG850, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1979 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 26: 2SA753 2SA753 2SA836 2SA836 2SA836 2SA836 2SA836 2SA844 2SB568 2SB568 2SB568 2SC458 2SC458 2SC1213 2SC1343 2SC1343 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SC1344 2SD478 2SD478 2SD478
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 120 W (unknown quality)
from Radiomuseum.org Model: VG850 - Uher Werke; München
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 135 x 297 mm / 17.1 x 5.3 x 11.7 inch
Notes HiFi-Verstärker mit 2 x 60 Watt Sinus an 4 Ohm. 7 Eingänge, Mikrofoneingang mit Überblendeinsteller. Subsonicfilter, Monitorschalter für Hinterbandkontrolle, Kopierschalter, LED-Funktionsanzeigen, Kopfhörerausgang, LS-Gruppenschalter.
Gehäuseausführung Schwarz mit eloxierter Alu-Front.
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Source of data - - Data from my own collection
Mentioned in -- Original prospect or advert

Model page created by Peter Böhm. See "Data change" for further contributors.
