Courier Kingfisher RW Mantel

Ultimate (Brand), Radio Ltd. & Radio (1936) Ltd.; Auckland

Data
Forum
Pictures
Collections

  • Year
  • 1948
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 361137

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 460 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 50Hz, 230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Courier Kingfisher RW [Mantel] - Ultimate Brand, Radio Ltd. &
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • Courier RW Kingfisher

    6-VALVE DUAL WAVE MODEL Housed in a distinctive cabinet of beautifully grained wood highly polished. Excellent reception on short wave as well as broadcast bands is assured. Fitted with an 8-inch high-fidelity speaker for superior performance. To fit a modern setting...to give peerless tone quality...choose this model.

    See also Golden Knight RW Console version.

    See also mantel versions Ultimate RW, Skyscraper RW, and Golden Knight RW.

  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
