Supervox UHF Konverter TC-64

Supervox UHF Konverter TC-64; Nogoton, (ID = 2436165) Converter Supervox UHF Konverter TC-64; Nogoton, (ID = 1937507) Converter
Supervox UHF Konverter TC-64; Nogoton, (ID = 664272) Converter Supervox UHF Konverter TC-64; Nogoton, (ID = 667605) Converter
Supervox UHF Konverter TC-64; Nogoton, (ID = 1937508) Converter Supervox UHF Konverter TC-64; Nogoton, (ID = 1937509) Converter
Supervox UHF Konverter TC-64; Nogoton, (ID = 1937510) Converter Supervox UHF Konverter TC-64; Nogoton, (ID = 2436166) Converter
Supervox UHF Konverter TC-64; Nogoton, (ID = 2436167) Converter Supervox UHF Konverter TC-64; Nogoton, (ID = 2436168) Converter
Use red slider bar for more.
Supervox UHF Konverter TC-64; Nogoton, (ID = 2436165) Converter
Nogoton,: Supervox UHF Konverter TC-64 [Converter] ID = 2436165 1300x649
Select picture or schematic to display from thumbnails on the right and click for download.
For model Supervox UHF Konverter TC-64, Nogoton, Norddeutsche Gerätebau; Delmenhorst/Oldenburg

Country:  Germany
Manufacturer / Brand:  Nogoton, Norddeutsche Gerätebau; Delmenhorst/Oldenburg
Brand

Noroton
Year: 1964 ? Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Semiconductors (the count is only for transistors) 2: AF139 AF139
schematic requested
Main principle RF Converter/Adapter (not voltage converter)
Wave bands Wave Bands given in the notes.
Details Converter
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Supervox UHF Konverter TC-64 - Nogoton, Norddeutsche
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes Supervox TC-64; UHF Konverter, Kanalskala 20 bis 70, Umsetzung auf VHF Kanal 2 bis 4, Fernsehstromsteckdose und Banansteckerantennenbuchsen, baugleich mit Nogoton TC-64 Konverter daher Nogoton als Hersteller/Zulieferer angenommen.

Model page created by a member from A. See "Data change" for further contributors.
