Pontiac Be-Box E39U

Pontiac Be-Box E39U; Novak also Pontiac; (ID = 694638) Radio

Pontiac Be-Box E39U; Novak also Pontiac; (ID = 694641) Radio
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179825) Radio Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179829) Radio
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179828) Radio Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179827) Radio
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179830) Radio Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179831) Radio
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179833) Radio Pontiac Be-Box E39U; Novak also Pontiac; (ID = 321156) Radio
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 321157) Radio Pontiac Be-Box E39U; Novak also Pontiac; (ID = 321158) Radio
Use red slider bar for more.
Pontiac Be-Box E39U; Novak also Pontiac; (ID = 179825) Radio
Novak also Pontiac;: Pontiac Be-Box E39U [Radio] ID = 179825 933x668
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pontiac Be-Box E39U, Novak (also Pontiac); Bruxelles

Country:  Belgium
Manufacturer / Brand:  Novak (also Pontiac); Bruxelles
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UBC41 UL41 UY41
Main principle Superheterodyne (common); 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-130; 220-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Pontiac Be-Box E39U - Novak also Pontiac; Bruxelles
Material Bakelite case
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 313 x 210 x 132 mm / 12.3 x 8.3 x 5.2 inch
Notes Scale lamp 18V/100 mA.
Loop antenna on backside panel.
Am Schaltplan steht 1959, auf der Stückliste 1952.
Price in first year of sale 1'995.00 BEF
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Schematic

Model page created by Daniel Altmann. See "Data change" for further contributors.
