Crusader XK

Crusader XK; Pan International (ID = 2279728) Radio

Crusader XK; Pan International (ID = 2279729) Radio

Crusader XK; Pan International (ID = 2279730) Radio

Crusader XK; Pan International (ID = 2279732) Radio

Crusader XK; Pan International (ID = 2279733) Radio

Crusader XK; Pan International (ID = 2279734) Radio
Crusader XK; Pan International (ID = 2279735) Radio Crusader XK; Pan International (ID = 872127) Radio
Crusader XK; Pan International (ID = 162424) Radio Crusader XK; Pan International (ID = 872123) Radio
Crusader XK; Pan International (ID = 1042694) Radio Crusader XK; Pan International (ID = 162425) Radio
Crusader XK; Pan International (ID = 162426) Radio Crusader XK; Pan International (ID = 852812) Radio
Crusader XK; Pan International (ID = 872129) Radio Crusader XK; Pan International (ID = 1042690) Radio
Use red slider bar for more.
Crusader XK; Pan International (ID = 2279735) Radio
Pan International: Crusader XK [Radio] ID = 2279735 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Crusader XK, Pan International GmbH, Pan Elektronik; Aachen, Würselen, Hamburg

Country:  Germany
Manufacturer / Brand:  Pan International GmbH, Pan Elektronik; Aachen, Würselen, Hamburg
Year: 1970–1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes unknown_Tube
Semiconductors (the count is only for transistors) 13: µPC1213
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Crusader XK - Pan International GmbH, Pan
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 360 x 290 x 130 mm / 14.2 x 11.4 x 5.1 inch
Notes

Frequenzbereiche:
AM 535-1605 kHz, SW1-SW2 3,9-12,5 MHz,
FM-TV1 59-108 MHz, TV2 176-218 MHz,
AIR-PB-WB 108-175 MHz,
CB 26,965 - 27,405; 40 Channel FM;
Anschlüsse für Außenantenne, Mikrofon und Kopfhörer; AFC, Squelch-Regler, Feldstärke-/Batterieanzeige und Feinabstimmung (nur für SW1/2) vorhanden.
Stromversorgung: 220 V AC, 4 x 1,5 V Batterie oder 12 V DC.

Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Collectors' prices

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Pan International GmbH, Pan Elektronik; Aachen, Würselen, Hamburg
Here you find 39 models, 33 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
