Handheld Transceiver (4 Watt - 3 Channel) BC-5802

Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391904) Citizen Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391905) Citizen
Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391908) Citizen Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391910) Citizen
Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391915) Citizen Handheld Transceiver BC-5802; Polmar; Milano (ID = 1650689) Citizen
Handheld Transceiver BC-5802; Polmar; Milano (ID = 1650687) Citizen Handheld Transceiver BC-5802; Polmar; Milano (ID = 1650688) Citizen
Handheld Transceiver BC-5802; Polmar; Milano (ID = 1650690) Citizen Handheld Transceiver BC-5802; Polmar; Milano (ID = 1650691) Citizen
Use red slider bar for more.
Handheld Transceiver BC-5802; Polmar; Milano (ID = 2391904) Citizen
Polmar; Milano: Handheld Transceiver BC-5802 [Citizen] ID = 2391904 1153x2050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Handheld Transceiver (4 Watt - 3 Channel) BC-5802, Polmar; Milano

Country:  Italy
Manufacturer / Brand:  Polmar; Milano
Year: 1985 ?? Category: Citizen Band Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Transceiver
Wave bands Short Wave (SW only)
Details
Power type and voltage Batteries / addl. power jack / 10 x 1,5 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out
from Radiomuseum.org Model: Handheld Transceiver BC-5802 - Polmar; Milano
Material Metal case
Dimensions (WHD) 78 x 215 x 57 mm / 3.1 x 8.5 x 2.2 inch
Notes

Ricetrasmittente POL MAR per banda cittadina CB 27 MHz quarzato in ricezione ed in trasmissione (3 quarzi in ricezione + 3 quarzi in trasmissione).
Commutatore di potenza  in uscita Hi-Lo.

Made in Taiwan

Net weight (2.2 lb = 1 kg) 0.750 kg / 1 lb 10.4 oz (1.652 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.



All listed radios etc. from Polmar; Milano
Here you find 5 models, 5 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
