Harvey Graphic Equalizer Booster

Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325425) Ampl/Mixer Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325424) Ampl/Mixer
Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325426) Ampl/Mixer Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325427) Ampl/Mixer
Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325428) Ampl/Mixer Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325429) Ampl/Mixer
Use red slider bar for more.
Harvey Graphic Equalizer Booster ; Unknown - CUSTOM (ID = 2325425) Ampl/Mixer
Unknown - CUSTOM: Harvey Graphic Equalizer Booster [Ampl/Mixer] ID = 2325425 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Harvey Graphic Equalizer Booster, Unknown - CUSTOM BUILT: Taiwan (RC)

Country:  Taiwan (Republic of China)
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Taiwan (RC)
Year: 1980 ?? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: Harvey Graphic Equalizer Booster - Unknown - CUSTOM BUILT: Taiwan
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 155 x 40 x 160 mm / 6.1 x 1.6 x 6.3 inch
Notes

equalizzatore grafico a 5 bande (60 Hz - 250 Hz - 1 kHz - 3.5 kHz - 10 kHz) - commutatore boost/bypass - fader - potenza uscita 30 + 30 watt max. - impedenza altoparlanti 4 Ω - negativo a massa.



Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)
