HX-6B

HX-6B; Unknown - CUSTOM (ID = 2395825) Radio

HX-6B; Unknown - CUSTOM (ID = 2395826) Radio
HX-6B; Unknown - CUSTOM (ID = 2395822) Radio HX-6B; Unknown - CUSTOM (ID = 2395823) Radio
HX-6B; Unknown - CUSTOM (ID = 2395824) Radio
Use red slider bar for more.
HX-6B; Unknown - CUSTOM (ID = 2395822) Radio
Unknown - CUSTOM: HX-6B [Radio] ID = 2395822 800x524
Select picture or schematic to display from thumbnails on the right and click for download.
For model HX-6B, Unknown - CUSTOM BUILT: China:
Teile-Übersicht

Country:  People's Republic of China
Manufacturer / Brand:  Unknown - CUSTOM BUILT: China
Year: 2017 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: S9018 S9018 S9018 S9014 S9013 S9013
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out
from Radiomuseum.org Model: HX-6B - Unknown - CUSTOM BUILT: China
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 125 x 75 x 26 mm / 4.9 x 3 x 1 inch
Notes

Color: light blue

Price in first year of sale 5.00 EUR

Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
