SSV - FM Radio with USB / SD NS-018U
Unknown - CUSTOM BUILT: China
- Country
- People's Republic of China
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: China
- Year
- 2010 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 302280
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- FLL, Frequency-locked loop (not PLL)
- Wave bands
- FM Broadcast Band Only
- Details
- HD or solid state memory
- Power type and voltage
- Line plus power jack, mostly with battery or storage battery / AC 220 / DC 4.5 / 4 x 1.5 or 4 x 1.2 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SSV - FM Radio with USB / SD NS-018U - Unknown - CUSTOM BUILT: China
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 95 x 120 x 55 mm / 3.7 x 4.7 x 2.2 inch
- Notes
-
Works on accus or dry batteries. AC connection for charging only.
Also sold under the brand name NNS in Eastern Europe.
- Net weight (2.2 lb = 1 kg)
- 0.352 kg / 0 lb 12.4 oz (0.775 lb)
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
