Jet AM/FM 36PT-S6

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726399) Radio

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726400) Radio

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726401) Radio

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726403) Radio

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726404) Radio

Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726405) Radio
Use red slider bar for more.
Jet AM/FM 36PT-S6; Vanguard; Hospitalet (ID = 1726399) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Spain
Manufacturer / Brand:  Vanguard; Hospitalet de Llobregat
alternative name

Cahué Industrial
Year: 1970 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: SF115 SF115 SF115 SF115 SF115 2N4286 2N4290 AC188 AC187 BD235 SFD107 SFD112 OA90 AA119 1N542
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz; 3 AF stage(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out 0.35 W (undistorted)
from Radiomuseum.org Model: Jet AM/FM 36PT-S6 - Vanguard; Hospitalet de
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 185 x 107 x 82 mm / 7.3 x 4.2 x 3.2 inch
Net weight (2.2 lb = 1 kg) 0.850 kg / 1 lb 14 oz (1.872 lb)
Literature/Schematics (2) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
