• Year
  • 1952
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 85834

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 465 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110, 127, 220 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Baltika - Балтика [6Б8 ] - VEF Radio Works Valst
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 500 x 360 x 280 mm / 19.7 x 14.2 x 11 inch
  • Notes
  • The removing variant from "Baltika RZ-1" in 6 tubes to the "Baltika - 52" in 7 tubes.
  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Mentioned in
  • Past Soviet Union magazine RADIO Nr.01 - 1953
  • Author
  • Model page created by a member from LV. See "Data change" for further contributors.
