Favorit Precolor TA-2151

Favorit Precolor TA-2151; Videoton; (ID = 1539336) Television Favorit Precolor TA-2151; Videoton; (ID = 1539338) Television
Favorit Precolor TA-2151; Videoton; (ID = 1539339) Television
Use red slider bar for more.
Favorit Precolor TA-2151; Videoton; (ID = 1539336) Television
Videoton;: Favorit Precolor TA-2151 [Television] ID = 1539336 933x745
Select picture or schematic to display from thumbnails on the right and click for download.
For model Favorit Precolor TA-2151, Videoton; Székesfehérvár:
Front view, working state

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1973 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 13: PCC189 PCF80 PCF201 PCF200 PCL84 PCF80 PCL86 PL500 PY88 DY86 PCL85 EF80 A47-17W
Semiconductors (the count is only for transistors) 2: AF139
Main principle Superheterodyne (common); ZF/IF 38000 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.2 W (undistorted)
from Radiomuseum.org Model: Favorit Precolor TA-2151 - Videoton; Székesfehérvár
Material Wooden case
Notes

Minimal tube count, simple construction, VHF 12 channels, UHF channels 21-68 (4 mechanical presets), sound 5.5 and 6.5Mhz (by 1Mhz oscillator with EF80), sensitivity 100uV VHF, 200uV UHF, tone frequency range 100Hz - 9Khz, power consuption 170W

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
