Sensor Star TA 3215
Use red slider bar for more.
Videoton;: Sensor Star TA 3215 [Television] ID = 713788 933x784
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
VTTV | ||||
|---|---|---|---|---|---|
| Year: 1975–1977 | Category: Television Receiver (TV) or Monitor | ||||
| Valves / Tubes | 6: ECC82 PL504 PCL85 PCL85 PCL84 PCL86 | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Wave Bands given in the notes. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | |
| from Radiomuseum.org | Model: Sensor Star TA 3215 - Videoton; Székesfehérvár |
| Dimensions (WHD) | 630 x 440 x 340 mm / 24.8 x 17.3 x 13.4 inch |
| Notes | OIRT and CCIR I., II., III. and UHF. 4 IC-s. Screen: 51 cm. 6 sensor preselection knob. |
| Net weight (2.2 lb = 1 kg) | 23 kg / 50 lb 10.6 oz (50.661 lb) |
| Source of data | Radio- es TV- kapcsolások, 1975-77 |
Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
