For model Szimfónia R946F II. (2), Videoton; Székesfehérvár:
Thanks for Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1958–1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 ECH81 EBL21 EZ80 EM80
Main principle Superheterodyne (common); ZF/IF 473,6 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Szimfónia R946F II. - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 330 x 250 mm / 19.7 x 13 x 9.8 inch
Notes SW1= 16-50 m, SW2= 50-150 m, Marine band. Speaker, oval: 210×150 mm.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 1'400.00 HUF
Source of data Radio es Televizio Vevö Keszülekek, 1958-59

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
