For model CN381B, Vidor Ltd.; Erith (Kent)

Country:  Great Britain (UK)
Manufacturer / Brand:  Vidor Ltd.; Erith (Kent)
Year: 1950 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK91 DF91 DAF91 DL94
schematic requested
Main principle Super-Heterodyne (Super in general); ZF/IF 475 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 1.5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: CN381B - Vidor Ltd.; Erith Kent
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 11.5 x 4 x 8 inch / 292 x 102 x 203 mm
Notes

Colours: Dark Red or Dark Green or Dark Brown/Cream Lizard.
Earlier models had an IF of 456 Khz. Same as model 381A except medium wave aerial trimmer is omitted also CN381 used DL92 (1948)

Net weight (2.2 lb = 1 kg) 2.4 kg / 5 lb 4.6 oz (5.286 lb)
Mentioned in Attaché Radios, by Mark Johnson
Literature/Schematics (1) Paul Stennings CD vol 4.

Model page created by Keith Staines. See "Data change" for further contributors.
