A 15W

A 15W; Voima, Helsinki (ID = 1969676) Ampl/Mixer A 15W; Voima, Helsinki (ID = 2071586) Ampl/Mixer
A 15W; Voima, Helsinki (ID = 2071587) Ampl/Mixer A 15W; Voima, Helsinki (ID = 2071588) Ampl/Mixer
A 15W; Voima, Helsinki (ID = 2071589) Ampl/Mixer A 15W; Voima, Helsinki (ID = 2071590) Ampl/Mixer
A 15W; Voima, Helsinki (ID = 2071591) Ampl/Mixer A 15W; Voima, Helsinki (ID = 2071592) Ampl/Mixer
Use red slider bar for more.
A 15W; Voima, Helsinki (ID = 1969676) Ampl/Mixer
Voima, Helsinki: A 15W [Ampl/Mixer] ID = 1969676 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model A 15W, Voima, Helsinki

Country:  Finland
Manufacturer / Brand:  Voima, Helsinki
Year: 1959 Category: Audio Amplifier or -mixer
Valves / Tubes 5: EF86 ECC85 ECC85 EL84 EL84
Semiconductors (the count is only for transistors) Selen
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 127; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: A 15W - Voima, Helsinki
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 385 x 190 x 230 mm / 15.2 x 7.5 x 9.1 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from Voima, Helsinki
Here you find 8 models, 5 with images and 5 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
