Vielfachmessgerät C4342-M1 {Ц4342-М1}

Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455314) Equipment Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1714587) Equipment
Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455311) Equipment Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455316) Equipment
Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455317) Equipment Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455319) Equipment
Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1714588) Equipment Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1714589) Equipment
Use red slider bar for more.
Vielfachmessgerät C4342-M1 {Ц4342-М1}; Sarapoul Orjonikidze (ID = 1455314) Equipment
Sarapoul Orjonikidze: Vielfachmessgerät C4342-M1 {Ц4342-М1} [Equipment] ID = 1455314 933x658
Select picture or schematic to display from thumbnails on the right and click for download.
For model Vielfachmessgerät C4342-M1 {Ц4342-М1}, Sarapoul Orjonikidze Radio Works

Country:  Soviet Union
Manufacturer / Brand:  Sarapoul Orjonikidze Radio Works
Year: 1991 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 2: КТ315 КТ315 Д9 Д9 КД521 КД521 КМП203УП1
Wave bands - without
Details
Power type and voltage Dry Batteries / 3x 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Vielfachmessgerät C4342-M1 {Ц4342-М1} - Sarapoul Orjonikidze Radio
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 210 x 78 x 110 mm / 8.3 x 3.1 x 4.3 inch
Notes

Analog Multimeter. Vdc, Vac, Adc, Aac, Ohm, dB, Transistor: PNP, NPN. Four-pin socket for transistor measurements.



Model page created by Massimo Follaro. See "Data change" for further contributors.
