• Country
• Italy

• Manufacturer / Brand
• Watt Radio; Torino

• Year
• 1961/1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 152277

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC170 OC169 OC169 OA90 OC75 OC74 OC74

• Main principle
• Superheterodyne (common); ZF/IF 462 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 0.3 W (max.)

• from Radiomuseum.org
• Model: WR-8 - Watt Radio; Torino

• Shape
• Portable set > 8 inch (also usable without mains)

• Source of data
• -- Original-techn. papers.

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Ignacio Rodriguez-Rodriguez. See "Data change" for further contributors.
