246GW; Wega, (ID = 30549) Radio
Wega,: 246GW [Radio] ID = 30549 933x696
Select picture or schematic to display from thumbnails on the right and click for download.
For model 246GW, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1948/1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: RV12P2000 RV12P2000 RV12P2000
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: 246GW - Wega, Württembergische Radio-
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 310 x 240 mm / 20.1 x 12.2 x 9.4 inch
Notes später mit U21er-Röhren.
Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)
Collectors' prices
Source of data Das Rundfunk-Jahr 1948/49 / Radiokatalog Band 1, Ernst Erb
Mentioned in Funk-Technik (FT) (4816)
Picture reference Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
