Concept 51K

Concept 51K; Wega, (ID = 745369) Radio

Concept 51K; Wega, (ID = 745370) Radio

Concept 51K; Wega, (ID = 745375) Radio

Concept 51K; Wega, (ID = 745376) Radio

Concept 51K; Wega, (ID = 745377) Radio

Concept 51K; Wega, (ID = 745378) Radio

Concept 51K; Wega, (ID = 745371) Radio

Concept 51K; Wega, (ID = 745372) Radio

Concept 51K; Wega, (ID = 745373) Radio

Concept 51K; Wega, (ID = 745374) Radio
Concept 51K; Wega, (ID = 2108701) Radio Concept 51K; Wega, (ID = 2108700) Radio
Concept 51K; Wega, (ID = 2108702) Radio Concept 51K; Wega, (ID = 98135) Radio
Concept 51K; Wega, (ID = 2177206) Radio Concept 51K; Wega, (ID = 851112) Radio
Concept 51K; Wega, (ID = 851113) Radio Concept 51K; Wega, (ID = 851114) Radio
Concept 51K; Wega, (ID = 851115) Radio Concept 51K; Wega, (ID = 851116) Radio
Use red slider bar for more.
Concept 51K; Wega, (ID = 2108701) Radio
Wega,: Concept 51K [Radio] ID = 2108701 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Concept 51K, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Other Combination - see Notes
Power type and voltage Line (AC, UC or DC not known) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Concept 51K - Wega, Württembergische Radio-
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 840 x 135 x 395 mm / 33.1 x 5.3 x 15.6 inch
Notes

Wega HiFi-Kompaktanlage 51K mit Plattenspieler und Cassetten-Deck.
Design: Hartmut Esslinger.

Optional war ein spezieller Standfuss UG51 verfügbar, den es mit oder ohne einen integrierten Lautsprecher gab.

Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Mentioned in Funkschau (22/1978, S. 1074)

Model page created by Markus Nüdling. See "Data change" for further contributors.
