D-1645 Truetone

D-1645 Truetone ; Western Auto Supply (ID = 85425) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488310) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488311) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488312) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488313) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488314) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488315) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488316) Radio

D-1645 Truetone ; Western Auto Supply (ID = 488317) Radio
D-1645 Truetone ; Western Auto Supply (ID = 2372162) Radio D-1645 Truetone ; Western Auto Supply (ID = 2372161) Radio
D-1645 Truetone ; Western Auto Supply (ID = 2372163) Radio D-1645 Truetone ; Western Auto Supply (ID = 2372164) Radio
D-1645 Truetone ; Western Auto Supply (ID = 2372165) Radio D-1645 Truetone ; Western Auto Supply (ID = 2372166) Radio
D-1645 Truetone ; Western Auto Supply (ID = 2372167) Radio D-1645 Truetone ; Western Auto Supply (ID = 2060858) Radio
D-1645 Truetone ; Western Auto Supply (ID = 488308) Radio D-1645 Truetone ; Western Auto Supply (ID = 488309) Radio
Use red slider bar for more.
D-1645 Truetone ; Western Auto Supply (ID = 2372162) Radio
Western Auto Supply: D-1645 Truetone [Radio] ID = 2372162 768x934
Select picture or schematic to display from thumbnails on the right and click for download.
For model D-1645 Truetone, Western Auto Supply Co. (Truetone); Kansas City (MO)

Country:  United States of America (USA)
Manufacturer / Brand:  Western Auto Supply Co. (Truetone); Kansas City (MO)
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SA7 6SK7 6SF7 6SJ7 6V6GT 6X5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 105 - 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out 2.3 W (unknown quality)
from Radiomuseum.org Model: D-1645 Truetone - Western Auto Supply Co.
Material Wooden case
Shape Console with any shape - in general
Notes Factory Model 26A76-650
Photofact see under Trade name: Truetone.
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
Mentioned in Beitman Radio Diagrams, Vol. 07, 1947
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 6, Folder 466-33)


All listed radios etc. from Western Auto Supply Co. (Truetone); Kansas City (MO)
