- Country
- Spain
- Manufacturer / Brand
- Westinghouse, Frimotor; Bilbao
- Year
- 1970 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 250455
- Number of Tubes
- 16
- Valves / Tubes
- PC900 PCF80 EH90 EF184 PCL84 PCL83 EF85 EF85 EF80 PCF80 PCL805 PCL82 PL500 PY88 DY87 unknown_CRT
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 3 W (3.5 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: E601P - Westinghouse, Frimotor; Bilbao
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 718 x 510 x 425 mm / 28.3 x 20.1 x 16.7 inch
- Notes
-
Model most likely built in Spain or Europe.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Price in first year of sale
- 9,000.00 PTE
- Author
- Model page created by Manuel Albano Neves. See "Data change" for further contributors.
