Half Section Separator Unit HS/CR3 /2
Wharfedale (Brand), Wharfedale Wireless Works, Rank Wharfedale Ltd.; Bradford
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Wharfedale (Brand), Wharfedale Wireless Works, Rank Wharfedale Ltd.; Bradford
- Year
- 1950 ??
- Category
- Miscellaneous (Other, Various) - see notes
- Radiomuseum.org ID
- 229577
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- - This model requires external speaker(s).
- from Radiomuseum.org
- Model: Half Section Separator Unit HS/CR3 /2 - Wharfedale Brand, Wharfedale
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 230 x 145 x 110 mm / 9.1 x 5.7 x 4.3 inch
- Notes
-
Cross-Over Frequencies 800 & 5000 CPS.
- Author
- Model page created by a member from A. See "Data change" for further contributors.
