Dwarf - Knirps - Zwerg
Wobbe-Radio; Winsen, später Rendsburg bei Kiel
- Country
- Germany
- Manufacturer / Brand
- Wobbe-Radio; Winsen, später Rendsburg bei Kiel
- Year
- 1947/1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 17665
- Number of Tubes
- 2
- Main principle
- TRF with regeneration; 1 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
- from Radiomuseum.org
- Model: Dwarf - Knirps - Zwerg - Wobbe-Radio; Winsen, später
- Dimensions (WHD)
- 106 x 78 x 65 mm / 4.2 x 3.1 x 2.6 inch
- Notes
- höchstens kl.Serie! [329, FT4812]
- Net weight (2.2 lb = 1 kg)
- 0.6 kg / 1 lb 5.1 oz (1.322 lb)
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Funkgeschichte der GFGF (9180)
- Literature/Schematics (1)
- Radio-Mentor (7/1948)
