Yaecon 6 Transistor YTR-58

Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 2567198) Radio
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419182) Radio Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419178) Radio
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419181) Radio Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419183) Radio
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419184) Radio Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419185) Radio
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419186) Radio Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419187) Radio
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419188) Radio
Use red slider bar for more.
Yaecon 6 Transistor YTR-58; Yamada Electric Ind. (ID = 1419182) Radio
Yamada Electric Ind.: Yaecon 6 Transistor YTR-58 [Radio] ID = 1419182 933x1357
Select picture or schematic to display from thumbnails on the right and click for download.
For model Yaecon 6 Transistor YTR-58, Yamada Electric Ind. Co., Ltd. (Yaecon); Tokyo:
Thanks for Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Japan
Manufacturer / Brand:  Yamada Electric Ind. Co., Ltd. (Yaecon); Tokyo
Year: 1961 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2S52 2S53 2S53 2S54 2S56 2S56
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 1 × 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Yaecon 6 Transistor YTR-58 - Yamada Electric Ind. Co., Ltd.
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 64 x 105 x 33 mm / 2.5 x 4.1 x 1.3 inch
Notes

see also:

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Yamada Electric Ind. Co., Ltd. (Yaecon); Tokyo
Here you find 10 models, 10 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
