CDX-700; Yamaha Co.; (ID = 1026551) R-Player
CDX-700; Yamaha Co.; (ID = 1026552) R-Player
CDX-700; Yamaha Co.; (ID = 1026554) R-Player
CDX-700; Yamaha Co.; (ID = 1026555) R-Player
CDX-700; Yamaha Co.; (ID = 1026557) R-Player
CDX-700; Yamaha Co.; (ID = 1026545) R-Player
Use red slider bar for more.
CDX-700; Yamaha Co.; (ID = 1026545) R-Player
Yamaha Co.;: CDX-700 [R-Player] ID = 1026545 933x617
Select picture or schematic to display from thumbnails on the right and click for download.
For model CDX-700, Yamaha Co.; Hamamatsu:
Original Yamaha Prospect
Country:  Japan
Manufacturer / Brand:  Yamaha Co.; Hamamatsu
alternative name
Nippon Gakki
Year: 1987 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Model: CDX-700 - Yamaha Co.; Hamamatsu
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 107 x 347 mm / 17.1 x 4.2 x 13.7 inch
Notes Compact Disc Player. Hi-Bit Digitalfilter mit Vierfach-Oversampling, aktiver-Analogfilter 3.Ordnung mit geringer Flankensteilheit, Dreistrahl-Laser, Servogesteuerte LSI-Abtastung.
Subchassis, 24 Titel durch direkte Anwahl, beliebig programmierbare Wiedergabe, Delete Programm, Random Play, 8-stellige Fluoreszenzanzeige, Index-Suchlauf, 4-fache Wiederholfunktion, Manual Space Insert, Timer-Wiedergabe, Kopfhörerausgang mit Pegelregler, Fernsteuerung mit 32 Tasten, integriert im RS-Fernsteuersystem.
Net weight (2.2 lb = 1 kg) 4.2 kg / 9 lb 4 oz (9.251 lb)
Price in first year of sale 1'030.00 DM
Source of data -- Original prospect or advert

Model page created by a member from D. See "Data change" for further contributors.
