Natural Sound Stereo Cassette Deck K-960

Yamaha Co.; Hamamatsu

  • Year
  • 1981/1982
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 153415
    • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Natural Sound Stereo Cassette Deck K-960 - Yamaha Co.; Hamamatsu
  • Shape
  • Book-shelf unit.
  • Notes
  • Frontloading 2-Head Stereo Cassette Deck with Dolby B, MPX Filter, Subsonic Filter, DBX Type II and Metal Tape Capability.
    3-Digit Mechanical Counter, Digital Peak-Reading Meters.
    Bias Fine Tune.
    Wired Remote Control.
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
