Natural Sound Compact Disc Player CDX-920

Yamaha Co.; Hamamatsu

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Yamaha Co.; Hamamatsu

Year
1989

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
201494

- alternative name: Nippon Gakki

Schematics

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048540) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048541) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048542) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048543) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048544) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048545) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048547) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048548) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048550) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048551) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048552) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048554) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048555) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048556) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048557) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048558) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048559) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048561) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048562) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048563) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048565) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048566) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048568) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048569) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048570) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048571) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048572) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048573) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048574) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048575) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (3)

Natural Sound Compact Disc Player CDX-920; Yamaha Co.; (ID = 1048539) R-Player — Yamaha Co.; Natural Sound Compact Disc Player CDX-920 (2)
Original Yamaha Prospect

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
Audio-Amplification

Wave bands
- without

Details
CD-Player, -Writer, MD, MOD (audio)

Power type and voltage
Alternating Current supply (AC) / 220 Volt

Loudspeaker
- For headphones or amp.

Material
Metal case

from Radiomuseum.org
Model: Natural Sound Compact Disc Player CDX-920 - Yamaha Co.; Hamamatsu

Shape
Book-shelf unit.

Dimensions (WHD)
435 x 106 x 357 mm / 17.1 x 4.2 x 14.1 inch

Notes
CD-Spieler. Achtfach Oversampling-Digitalfilter mit 18-bit Datenausgang, hochpräzise 18-bit DACs mit 4-bit Umschaltung, separate DACs für Links und Rechts, digitaler Deemphasis Schaltkreis, DAC-Direktausgang, digitale Lautstärkeregelung, optischer und koaxialer Digitalausgang, neuartiger Dreistrahl-Laser, Zweifach-Servo mit Mikrocomputersteuerung, 8-stellige Multifunktions-Fluoreszenzanzeige, 4-fache Zeitanzeige, Display Umschaltung, Tape Edit, Speicher für 24 Titel, 3-faches Programm, 5-fache Wiederholfunktion, direkter Titelzugriff, Kalender Display, 3-facher Musiksuchlauf, Index-Suchlauf, Auto Space Insert, 3-fache Timerwiedergabe, Kopfhörerbuchse mit Pegelregelung, CD Single geeignet, IR-Fernbedienung, integriert in das RS-Fernsteuersystem.

Net weight (2.2 lb = 1 kg)
8.5 kg / 18 lb 11.6 oz (18.722 lb)

Price in first year of sale
1,339.00 DM

Source of data
-- Original prospect or advert

Author
Model page created by a member from D. See "Data change" for further contributors.
