Natural Sound Graphischer Equalizer EQ-550
Yamaha Co.; Hamamatsu
- Country
- Japan
- Manufacturer / Brand
- Yamaha Co.; Hamamatsu
- Year
- 1990–1999
- Category
- Miscellaneous (Other, Various) - see notes
- Radiomuseum.org ID
- 202972
-
- alternative name: Nippon Gakki
Original Yamaha Prospect
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Natural Sound Graphischer Equalizer EQ-550 - Yamaha Co.; Hamamatsu
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 435 x 100 x 232 mm / 17.1 x 3.9 x 9.1 inch
- Notes
- Graphischer Equalizer mit Spektrum-Analyzer. 10 Frequenzbänder pro Kanal, Analyzer mit Fluoreszenzanzeige, separate Ausgangspegelregler, Tape Monitor, Tonbandaufzeichnung des entzerrten Signals, schaltbarer Subsonicfilter, Generator für "Rosa Rauschen", mitgeliefertes Elektret-Kondensator-Mikrophon.
- Net weight (2.2 lb = 1 kg)
- 2.650 kg / 5 lb 13.4 oz (5.837 lb)
- Price in first year of sale
- 617.00 DM
- Source of data
- -- Original prospect or advert
- Author
- Model page created by a member from D. See "Data change" for further contributors.
