Natural Sound Stereo Receiver RX-396RDS

Yamaha Co.; Hamamatsu

Data
Forum
Pictures
Collections

  • Year
  • 1998–2002
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 214076
    • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 110 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Natural Sound Stereo Receiver RX-396RDS - Yamaha Co.; Hamamatsu
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 435 x 146 x 308.5 mm / 17.1 x 5.7 x 12.1 inch
  • Notes
  • HiFi Receiver UKW/MW mit RDS. Sinus 2x 50W an 8 Ohm, 2x 55W an 4 Ohm nach DIN, 5 Eingänge, 40 Stationsspeicher.
  • Net weight (2.2 lb = 1 kg)
  • 6.4 kg / 14 lb 1.6 oz (14.097 lb)
  • Price in first year of sale
  • 429.00 DM
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
