• Country
• Japan

• Manufacturer / Brand
• Yamaha Co.; Hamamatsu

• Year
• 1985/1986

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 198882

• • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 130 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: R-5 - Yamaha Co.; Hamamatsu

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 435 x 126 x 289 mm / 17.1 x 5 x 11.4 inch

• Notes
• HiFi Receiver mit MW/UKW, 2 x 48 W an 8 Ohm, 2 x 65 W an 4 Ohm nach DIN, 16 Stationsspeicher.

• Net weight (2.2 lb = 1 kg)
• 5.6 kg / 12 lb 5.4 oz (12.335 lb)

• Price in first year of sale
• 774.00 DM

• Source of data
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
