R-70; Yamaha Co.; (ID = 1006466) Radio
Yamaha Co.;: R-70 [Radio] ID = 1006466 933x442
Select picture or schematic to display from thumbnails on the right and click for download.
For model R-70, Yamaha Co.; Hamamatsu:
Original Yamaha Prospect

Country:  Japan
Manufacturer / Brand:  Yamaha Co.; Hamamatsu
alternative name

Nippon Gakki
Year: 1983/1984 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 110 W (unknown quality)
from Radiomuseum.org Model: R-70 - Yamaha Co.; Hamamatsu
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 122 x 386 mm / 17.1 x 4.8 x 15.2 inch
Notes Hifi Receiver, Sinusleistung 2x 55W an 8 Ohm nach DIN, Klangregler mit 5-Band-Equalizer, 10 UKW/MW Stationsspeicher, MC Phono-Eingang.
Net weight (2.2 lb = 1 kg) 8.3 kg / 18 lb 4.5 oz (18.282 lb)
Price in first year of sale 1'183.00 DM
Source of data -- Original prospect or advert

Model page created by a member from D. See "Data change" for further contributors.
