• Country
• Japan

• Manufacturer / Brand
• Yamaha Co.; Hamamatsu

• Year
• 1978–1980

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 156644

• • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Control Amplifier C-4 - Yamaha Co.; Hamamatsu

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 435 x 116 x 376 mm / 17.1 x 4.6 x 14.8 inch

• Notes
• Subsonic Filter 15Hz 12dB/oct.
  High Filter 10kHz 12dB/oct. For the japanese market (100 Volt mains).

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
