For model Stereo Turntable YP-800, Yamaha Co.; Hamamatsu:
Aus Original-Yamaha-Dokumentationen vom Hersteller.

Country:  Japan
Manufacturer / Brand:  Yamaha Co.; Hamamatsu
alternative name

Nippon Gakki
Year: 1974 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present. 2SC1061
Wave bands - without
Details Record Player (not changer); Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 100-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Turntable YP-800 - Yamaha Co.; Hamamatsu
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 481 x 175 x 371 mm / 18.9 x 6.9 x 14.6 inch
Notes

Hi-Fi-Stereo-Plattenspieler mit elektronisch geregelten 12-Pol-DC-Motor.
1 Transistor 2SC1061 im Netzteil plus Halbleiter in der Motorregelung.

Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Mentioned in -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
