T-550

T-550; Yamaha Co.; (ID = 1352940) Radio T-550; Yamaha Co.; (ID = 1352941) Radio
T-550; Yamaha Co.; (ID = 662052) Radio T-550; Yamaha Co.; (ID = 662053) Radio
T-550; Yamaha Co.; (ID = 1352942) Radio
Use red slider bar for more.
T-550; Yamaha Co.; (ID = 1352940) Radio
Yamaha Co.;: T-550 [Radio] ID = 1352940 900x482
Select picture or schematic to display from thumbnails on the right and click for download.
For model T-550, Yamaha Co.; Hamamatsu

Country:  Japan
Manufacturer / Brand:  Yamaha Co.; Hamamatsu
alternative name

Nippon Gakki
Year: 1980 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: T-550 - Yamaha Co.; Hamamatsu
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 435 x 92 x 341 mm / 17.1 x 3.6 x 13.4 inch
Notes

Stereo FM Tuner. LED-Signalqualitäts-Anzeige.

AM/FM Stereo Tuner - DC-NFB PLL MPX

Built-in Rec Cal Oscillator

Net weight (2.2 lb = 1 kg) 4.4 kg / 9 lb 11.1 oz (9.692 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
