• Year
  • 1987–1989
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 199881
    • alternative name: Nippon Gakki

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: TX-900 - Yamaha Co.; Hamamatsu
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 435 x 92.5 x 282.5 mm / 17.1 x 3.6 x 11.1 inch
  • Notes
  • Hi-Fi Tuner für MW und UKW. Neuartige Computer Servo Lock-Abstimmung, digitale Feinabstimmung, 20 Stationsspeicher zum Direktabruf, Sendersuchlauf und manuelle Abstimmung, automatische oder manuelle Wahl von 3 ZF-Betriebsarten, Speicherung von 4 Abstimmarten, Multifunktions LCD-Anzeige, High Blend Umschalter, Anzeige der Signalqualität durch 24 Segmente, Niederimpedanz MW-Rahmenantenne, integriert im RS-Fernsteuersystem.
  • Net weight (2.2 lb = 1 kg)
  • 3.3 kg / 7 lb 4.3 oz (7.269 lb)
  • Price in first year of sale
  • 825.00 DM
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
