• Country
• Austria

• Manufacturer / Brand
• Zehetner (Radiobau-Zehetner); Wien

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 25386

• Number of Transistors
• 7

• Semiconductors
• OC44 OC45 OC45 OC71 OC71 OC74 OC74

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Line / Batteries (any type) / 110-220 / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Brillant [Transistoren] - Zehetner Radiobau-Zehetner;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 200 x 145 x 60 mm / 7.9 x 5.7 x 2.4 inch

• Notes
• Gehäuse: Holzkassette mit abwaschbarem Plastiküberzug.

• Net weight (2.2 lb = 1 kg)
• 1.1 kg / 2 lb 6.8 oz (2.423 lb)

• Price in first year of sale
• 1,590.00 ATS

• Source of data
• Radiokatalog Band 2, Ernst Erb
