• Country
• Austria

• Manufacturer / Brand
• Zehetner (Radiobau-Zehetner); Wien

• Year
• 1949

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 25369

• Number of Tubes
• 4

• Valves / Tubes
• ECH21 ECH21 EBL21 AZ21

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Saphir W56 [var LMK] - Zehetner Radiobau-Zehetner;

• Dimensions (WHD)
• 350 x 265 x 180 mm / 13.8 x 10.4 x 7.1 inch

• Notes
• Phono-Anschluss; Stromverbrauch ca. 40W

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Price in first year of sale
• 996.00 ATS

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Other Models

• Here you find 67 models, 42 with images and 31 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Zehetner (Radiobau-Zehetner); Wien
