10S567 10-S-567 Ch= 10A1

10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 64126) Radio
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 2053101) Radio 10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 2053102) Radio
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 2053103) Radio 10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 2053104) Radio
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 66886) Radio 10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 87972) Radio
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 87975) Radio 10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 87974) Radio
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 87973) Radio 10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 87976) Radio
Use red slider bar for more.
10S567 10-S-567 Ch= 10A1; Zenith Radio Corp.; (ID = 2053101) Radio
Zenith Radio Corp.;: 10S567 10-S-567 Ch= 10A1 [Radio] ID = 2053101 1400x1837
Select picture or schematic to display from thumbnails on the right and click for download.
For model 10S567 10-S-567 Ch= 10A1, Zenith Radio Corp.; Chicago, IL

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 1232 6A8G 6K7G 6J5G 6F5G 6J5G 6V6G 6V6G 6X5G 6X5G
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 10S567 10-S-567 Ch= 10A1 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 29 x 42 x 16 inch / 737 x 1067 x 406 mm
Price in first year of sale 90.00 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Zenith Radio The Glory Years 1936-1945
Literature/Schematics (2) Radio Retailing (Radio & Television R.) (February 1942.)
