For model 834A Ch= 1002 nur für die Schweiz - only for Switzerland, Zenith Radio Corp.; Chicago, IL:
front sight

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1935 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6D6 6A7 76 6D6 6D6 75 42 42 42 5Z3
Main principle Superhet with RF-stage; ZF/IF 485 kHz; Export model
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 25-133 Hz, 117-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 834A Ch= 1002 [nur für die Schweiz - only for Switzerland] - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Notes Nur für die Schweiz. Gebaut nach Philips Standard mit Telefunken Lizenz.
Produced for the Swiss market only under Philips-Telefunken concession.
Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)

Model page created by Luca Posca. See "Data change" for further contributors.
