961 Ch= 2514; Zenith Radio Corp.; (ID = 710944) Radio
Zenith Radio Corp.;: 961 Ch= 2514 [Radio] ID = 710944 600x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model 961 Ch= 2514, Zenith Radio Corp.; Chicago, IL:
Zenith model 961 with courtesy by Walt Buffinton.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6D6 6A7 6D6 75 42 80
Main principle Superhet with RF-stage; ZF/IF 252 kHz
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: 961 Ch= 2514 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console with any shape - in general
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 6 = 1935 and before
Mentioned in Pre-War Consoles
